VFS5000A型盒式袋装粉剂包装机
----适用于奶粉，蛋白粉，咖啡，牛初乳，豆奶粉

推荐关键词搜索：全自动奶粉包装机|米粉包装机|豆奶粉包装机|蛋白粉包装机|咖啡粉包装机|牛初乳粉包装机

    全自动粉剂包装机是我公司最新研制出的一种制盒式袋机型，包装袋在立式袋基础上增封四个角边，使包装袋立体感更强，外观更加美观大方，使您的产品更具有吸引力。该包装机使用进口伺服电机走纸，人机界面使用先进技术触摸屏，使操作更加简单方便。

技术参数：

包装速度:20～50 包/分

最大包材宽度:540mm(四边封)/730mm(五边封)

制袋尺寸:

正面宽：80～160 mm/100~220mm

侧面宽：50～80 mm/ 60~110mm

边封宽：5～10 mm

长：80~340mm/100~420 mm

压缩空气要求：0.6 MPa 350L/min

电力用量：220 V 5.5 kW 50 Hz

外型尺寸：(1850×1300×2300) (mm)（长×宽×高）

机重： 1200 kg

VFS5000A BOX-TYPE BAG PACKAGING MACHINE
----Suitable for milk powder, powder materials automatic packaging

VFS5000A box-type bag packaging machine is a latest type developed by our company; the packaging bag is added with four gussets, making the packaging bag have stronger spatial sense and appearance more attraction. This packaging machine adopts import servo motor for paper feed and the man-machine interface uses advanced touch screen, making operation simpler and more convenient.

Technical parameters:

Packaging speed: 20～50 bags/min

Max. width of packaging material: 540mm/730 mm

Bag size:

Front width: 80～160 mm/100~220mm;

side width: 50～80 mm/ 60~110mm;

width of side seal: 5～10 mm;

length: 80~340mm/100~420 mm

Compressed air consumption: 0.6 MPa 350 L/min

Electric requirement: 220 V/5.5 kW 50 Hz

Unit weight: 1200 kg

External dimensions: (1850×1300×2300)(mm)(L×W×H)
